Al Vishwas Nickel Alloys, headquartered in Dubai, UAE, distinguishes itself as a leading manufacturer and supplier of Monel Forged Fittings, engineered for high-performance, corrosion-resistant piping systems. Driven by a firm commitment to quality and engineering excellence, the company manufactures precision-machined fittings built to satisfy the demanding requirements of marine, chemical, and offshore applications. Every fitting is produced through advanced forging methods and complies with stringent quality standards, guaranteeing exceptional durability and reliability. Al Vishwas Nickel Alloys takes pride in its customer-focused approach, on-time deliveries, and thorough technical support, positioning it as a preferred source for dependable Monel forged solutions throughout a wide range of industries.
Specifications :ASTM B564 & ASME SB564
Standard :ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size :1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class :2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type :Socketweld Fittings, Screwed-Threaded Fittings
Grades :Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500)
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Monel K500 | 0.25 max | 1.5 max | 0.5 max | 0.010 max | 27.00 – 33.00 | 0.5 – 2 | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
| Monel K500 | 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 160000 , MPa – 1100 | Psi – 115000 , MPa – 790 | 20 % |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Monel Forged Fittings in Dubai, UAE, delivering advanced solutions for every piping requirement you have. Our modern manufacturing facilities are strategically positioned in the UAE, enabling us to keep an extensive stock of more than 16,000 tons of high-quality materials available on hand. We are committed to supplying outstanding products and services, guaranteeing dependability and excellence for our clients worldwide.
Reach out to us for a fast quote tailored to your requirement.
Monel Forged Fittings are used across a range of industries where excellent corrosion resistance and mechanical strength are essential. They are commonly found in marine engineering systems, including seawater piping, pump assemblies, and desalination plants. Within the chemical and petrochemical sectors, these fittings play a vital role in processing lines, heat exchangers, and systems that handle corrosive fluids. Oil and gas refineries depend on them for high-pressure applications and sour gas environments.
