Al Vishwas Nickel Alloys, a well-regarded manufacturer and supplier based in Dubai, UAE, focuses on high-quality Monel K500 Sheets and Plates engineered for excellent performance in demanding industrial environments. Made from premium Monel K500 alloy, these sheets and plates offer exceptional strength, corrosion resistance, and lasting durability. Al Vishwas Nickel Alloys uses advanced manufacturing techniques and rigorous quality control measures to guarantee that each product meets international standards and satisfies customer requirements. Their Monel K500 Sheets and Plates are relied upon across marine, chemical, petrochemical, and offshore industries, where robust, corrosion-resistant materials are essential for safe and efficient operations.
Monel K500 Sheets and Plates are produced from a nickel-copper alloy that’s strengthened with aluminum and titanium, enabling precipitation hardening and better mechanical performance. They demonstrate high tensile and yield strength, remarkable hardness, and outstanding toughness, even at extreme temperatures. These sheets and plates offer strong resistance to seawater corrosion, along with acidic and alkaline environments, and they successfully resist stress-corrosion cracking. Featuring excellent fatigue strength, low magnetic permeability, and notable durability, Monel K500 Sheets and Plates preserve their structural integrity under high pressure, elevated temperatures, and demanding service conditions.
Specifications :ASTM B127 / ASME SB127, AMS 4544
Width :1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, and more
Length :2000mm, 2440mm, 3000mm, 5800mm, 4000mm, and so on
Thickness :0.3 mm up to 120 mm
Hardness :Soft, Hard, Half Hard, Quarter Hard, Spring Hard and others.
Finish :Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Form : Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange)
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel K500 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28 – 34 | 2.50 max | 63.00 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Monel K500 Sheet and Plates in Dubai, UAE, delivering advanced solutions for every one of your piping requirements. Our cutting-edge production facilities are strategically situated in the UAE, enabling us to keep a large stock of more than 16,000 tons of top-quality materials on hand and ready in inventory. We are committed to providing exceptional products and services, guaranteeing dependability and excellence for our worldwide customers.
Reach out to us for a fast quote on your requirement.
Monel K500 Sheets and Plates are widely applied across numerous industries requiring high strength, resistance to corrosion, and dependable performance. Within marine environments, they serve in pump parts, propeller systems, seawater handling equipment, and offshore structures. The chemical and petrochemical industries depend on them for reactors, heat exchangers, storage tanks, and processing units exposed to harsh chemicals. Furthermore, they are employed in oil and gas production equipment, aerospace components, and power generation systems, demonstrating their adaptability and reliability across a wide range of applications.
