Al Vishwas Nickel Alloys, based in Dubai, UAE, stands out as a top manufacturer and supplier of premium A286 Foil, designed specifically for challenging high-temperature and corrosion-resistant applications. Using cutting-edge manufacturing techniques and rigorous quality checks, the company creates foils that provide exceptional mechanical strength, resistance to oxidation, and lasting reliability. Al Vishwas Nickel Alloys offers A286 Foil in a variety of thicknesses and sizes to satisfy a wide range of industrial needs. Focusing on sectors like aerospace, power generation, automotive, and chemical processing, the company holds a solid reputation for supplying durable, high-performance nickel-iron-chromium alloy foils that excel in extreme thermal and corrosive environments.
A286 Foil is a nickel-iron-chromium superalloy composed of approximately 25–28% nickel and 15–16% chromium, along with small amounts of cobalt, titanium, and molybdenum that boost its high-temperature strength and corrosion resistance. This unique makeup delivers excellent oxidation and creep resistance even at elevated temperatures. Mechanically, A286 Foil exhibits impressive tensile and yield strength, outstanding fatigue resistance, and adequate ductility. Its capacity to maintain mechanical integrity under demanding thermal, oxidative, and corrosive conditions makes it well-suited for critical applications throughout aerospace, power generation, and high-performance industries where lasting durability is vital.
| Standard Specification : | AMS 5525, AMS 5858 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | C | Mn | Si | S | Co | Cu | Ni | Cr | P | V | Al | B |
| A286 | 0.08 max | 2 max | 1 max | 0.025 max | 1 max | 0.50 max | 24 – 27 | 13.5 – 16 | 0.025 max | 0.10 – 0.50 | 0.35 max | 0.003 – 0.010 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.92 g/cm3 | 2500-2600°F (1370-1430°C) | 90,000 psi (620MPa) | 40,000 psi (275 Mpa) | 40 % |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of A286 Foil in Dubai, UAE, providing cutting-edge solutions for all of your piping needs. Our state-of-the-art production facilities are strategically located in the UAE, allowing us to maintain a large inventory of over 16,000 tons of premium materials readily available in stock. We are dedicated to delivering exceptional products and services, ensuring reliability and quality for our global clients.
Contact us for a quick quote customized to what you require.
A286 Foil finds application in a wide range of industries demanding outstanding strength at high temperatures, oxidation resistance, and corrosion resilience. In the aerospace sector, it is used in turbine engine components, fasteners, and structural assemblies subjected to intense heat. The power generation industry uses A286 Foil in gas turbines, steam turbines, and heat exchangers. Chemical processing facilities depend on it for equipment and machinery that handle corrosive chemicals at high temperatures, ensuring reliability and performance under challenging conditions.
