Al Vishwas Nickel Alloys, headquartered in Dubai, UAE, is a trusted manufacturer and supplier of Copper Nickel Stud Bolts, delivering high-quality fastening solutions for marine, industrial, and chemical uses. These stud bolts are engineered to provide exceptional corrosion resistance, remarkable tensile strength, and enduring durability, guaranteeing dependable performance even in demanding conditions. Al Vishwas Nickel Alloys follows rigorous quality standards to supply consistent and accurate products. Copper Nickel Stud Bolts are used in seawater piping, offshore structures, desalination plants, and chemical processing equipment, forming secure and long-lasting joints capable of withstanding aggressive media, mechanical stress, and continuous exposure to salty and corrosive environments.
Copper Nickel Stud Bolts are primarily composed of 90% copper and 10% nickel (CuNi 90/10) or 70% copper and 30% nickel (CuNi 70/30), along with small quantities of iron and manganese. This alloy is recognized for its outstanding resistance to seawater corrosion, pitting, and biofouling, while also delivering high tensile strength, toughness, and ductility. The bolts show impressive fatigue resistance, thermal conductivity, and dimensional stability. The combination of mechanical strength and corrosion resistance ensures reliable performance in marine, offshore, and industrial environments where high stress and severe conditions are frequent.
| Material | Copper Nickel Hex Bolts |
|---|---|
| Grades | Cupro Nickel 90/10 and 70/30 |
| ASTM / ANSI | ASME SB 151/ ASTM B151 |
| Size | M2 – M160 |
| Threads: | BSW, METRIC, UNF, UNC, BSF,or as required |
| Copper Nickel Hex Bolts Length | 3 mm to 200 mm |
| other sizes | M20, M2, M12, M2.5, M10, M6, M24, M4, M3, M30, M5, M36, M8, M14, M16 etc. |
| Copper Nickel | Ni | Pb | Cu | Fe | Mn | Zn |
| 9-11 max | 0.05 max | 88.6 min | 1.8 max | 1.0 max | 1 max |
| Density | Elongation | Yield Strength (0.2%Offset) | Melting Point | Tensile Strength |
| 8.1 g/cm3 | 30 % | Psi – 35,000, MPa – 241 | 1443 °C (2430 °F) | Psi -80,000, MPa -551 |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Copper Nickel Stud Bolts in Dubai, UAE, delivering advanced solutions for every one of your piping requirements. Our cutting-edge manufacturing facilities are strategically situated in the UAE, enabling us to keep a large inventory of more than 16,000 tons of high-quality materials on hand and ready in stock. We are committed to providing exceptional products and services, guaranteeing dependability and excellence for our worldwide customers.
Reach out to us for a fast quote tailored to your requirement.
Copper Nickel Stud Bolts are widely employed in applications that demand corrosion-resistant and long-lasting fastening solutions. Within the marine and offshore sectors, they serve in seawater piping, hull fittings, and structural assemblies. Desalination plants and chemical processing facilities depend on these bolts to fasten equipment and pipelines exposed to aggressive chemicals and saline conditions. They are likewise present in heat exchangers, condensers, and power generation systems, where mechanical strength together with corrosion resistance is essential.
