Al Vishwas Nickel Alloys distinguishes itself as a premier manufacturer and supplier based in Dubai, UAE, specializing in premium Duplex Steel 2205 Sheets and Plates for a range of industrial applications. The company takes pride in its accuracy, advanced manufacturing methods, and stringent quality control, guaranteeing that their products satisfy global performance benchmarks. Their Duplex Steel 2205 Sheets and Plates are celebrated for their exceptional strength, corrosion resistance, and longevity, making them ideal for demanding conditions. With a firm focus on customer satisfaction and a dedication to delivering dependable, budget-friendly solutions, Al Vishwas Nickel Alloys has earned the confidence of industries that rely on high-performance materials for essential operations.
Specifications : ASTM A240 / ASME SA240
Dimensions : ASTM, ASME, and API
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Thickness : 4mm-100mm
Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Surface Finish : 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled plate (HR), Cold rolled sheet (CR), SATIN (Met with Plastic Coated) etc
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| Duplex 2205 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 21.0 – 23.0 | 2.50 – 3.50 | 4.50 – 6.50 | 0.8 – 0.20 | 63.54 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| 2205 | 7.805 | 0.285 | 1420 – 1465 | 2588 – 2669 |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Duplex 2205 Sheets and Plates in Dubai, UAE, delivering advanced solutions for every piping requirement you have. Our modern manufacturing facilities are strategically situated in the UAE, enabling us to keep an extensive stock of more than 16,000 tons of top-quality materials on hand and ready to ship. We are committed to providing exceptional products and services, guaranteeing dependability and excellence for our worldwide customers.
Reach out to us for a fast quote tailored to your needs.
Duplex Steel 2205 Sheets and Plates are widely applied across industries that require strong, corrosion-resistant, and durable materials. Within the oil and gas sector, they serve in offshore platforms, risers, storage tanks, and piping exposed to seawater and aggressive chemicals. Chemical and petrochemical plants depend on them for reactors, heat exchangers, and process equipment thanks to their outstanding resistance to hostile environments. They also play a vital role in desalination plants, pulp and paper processing, and pressure vessels, demonstrating their adaptability across a wide range of demanding uses.
