Al Vishwas Nickel Alloys, headquartered in Dubai, UAE, is a trusted manufacturer and supplier of Inconel 601 Stud Bolts. These high-performance bolts are engineered to provide exceptional strength, corrosion resistance, and durability even in the most demanding conditions. Through careful craftsmanship, Al Vishwas’s Inconel 601 Stud Bolts comply with rigorous industry standards, making them ideal for high-temperature applications. They provide reliable fastening solutions in industries where safety and longevity are of the utmost importance. Recognized for their remarkable resistance to oxidation and thermal degradation, these stud bolts are used in power plants, chemical processing facilities, aerospace components, and other challenging industrial environments.
Inconel 601 Stud Bolts are primarily composed of nickel and chromium, with minor quantities of iron, cobalt, and aluminum incorporated to enhance their high-temperature strength and corrosion resistance. These bolts demonstrate outstanding mechanical properties, such as high tensile and yield strength, resistance to creep and thermal fatigue, and superb stability under extreme conditions. The material’s capacity to withstand oxidation guarantees durable performance, even in aggressive chemical and thermal settings, while its toughness and dimensional stability make it perfect for critical engineering and industrial applications that demand dependable fastening solutions.
| Specification | ASTM F468, B166 / ASME SF468, SB166 |
|---|---|
| Size | M02 to M33, Custom Sizes |
| Length | 3 mm to 200 mm |
| Stud Bolt | UNF, BSW, BSF, METRIC, UNC, or as required |
| Standard | DIN 525, DIN 835, DIN 938, DIN 939, DIN 940, DIN 949-1, DIN 949-2, DIN 975, DIN 976, DIN 2509, BS 2693, BS 3692, BS 4439, IS 1862, IS 13178, ANSI/ASME B18.31.2, ANSI/ASME B16.5 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Types | Stud Bolts, Fully Threaded Stud Bolts, Tap End Stud Bolts, Double End Stud Bolts, Stud Bolts with Reduced Shank, Reduced Shank, Flange Stud Bolts, Flange Bolting, Weld Studs |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Test Certificate | as per EN 10204 / 3.1 Manufacturer Test Certificate |
| Additional Certifications | PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Production process | M24-M100: hot forging, M2-M24: Cold Froging, for custom-made connecting element machining and CNC |
| Head drive of Stud Bolts | Six-Lobe, Phillips, Phillips/Slot, Slotted etc |
| Packing of Stud Bolts | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Ptfe Coated Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 601 | 0.10 max | 1.0 max | 0.5 max | 0.015 max | 1.0 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 601 Stud Bolts in Dubai, UAE, delivering advanced solutions for every one of your piping requirements. Our modern manufacturing facilities are strategically situated in the UAE, enabling us to keep an extensive stock of more than 16,000 tons of top-quality materials on hand and ready for immediate supply. We are committed to providing outstanding products and services, guaranteeing dependability and excellence for our worldwide customers.
Reach out to us for a fast quote tailored to your requirement.
Inconel 601 Stud Bolts are widely applied in high-temperature and corrosive environments, including gas turbines, furnace assemblies, heat exchangers, and chemical processing equipment. Their exceptional resistance to oxidation, scaling, and thermal fatigue makes them a preferred option for the aerospace, power generation, and petrochemical sectors. These stud bolts are ideal for applications requiring secure and long-lasting fastening under extreme conditions, safeguarding the reliability and safety of equipment. Industries that demand rugged, high-performance fasteners rely on Al Vishwas Nickel Alloys’ Inconel 601 Stud Bolts to sustain operational efficiency, reduce maintenance costs, and deliver peace of mind.
