Al Vishwas Nickel Alloys, a leading manufacturer and supplier located in Dubai, UAE, focuses on premium Inconel X-750 Pipe engineered to perform in the most demanding environments. Backed by a strong reputation for their skill in high-performance nickel alloys, the company delivers pipes that offer outstanding strength, oxidation resistance, and enduring stability even under high temperatures. Manufactured with precision and dedication to international standards, Al Vishwas’s Inconel X-750 Pipes are ideal for uses that require superior durability and thermal dependability. They serve numerous industries, such as aerospace, chemical, power generation, and industrial, delivering trustworthy solutions that satisfy demanding operational and environmental requirements.
Inconel X-750 Pipe consists primarily of nickel and chromium, along with additional elements such as titanium, aluminum, iron, and niobium that enhance its precipitation hardening and thermal strength. This alloy demonstrates remarkable mechanical properties, including high tensile and yield strength, outstanding creep resistance, and stability at temperatures as high as 1300°F (704°C). It maintains its structural integrity throughout thermal cycling and holds up well against oxidation, corrosion, and stress corrosion cracking. Together, these characteristics make Inconel X-750 Pipe a perfect selection for components subjected to intense heat, pressure, and corrosive conditions.
| Standards : | ASTM B167, B517 / ASME SB167, SB517 |
| Dimensional : | ANSI/ASME B36.19M, ANSI/ASME B36.10M |
| Seamless Pipe Size : | 1 / 2″ NB – 16″ NB |
| Welded Pipe Size : | 1 / 2″ NB – 24″ NB |
| Outside Diameter : | 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available Ex-stock, OD Size Steel Tubes available Ex-stock |
| Pipe Type : | Seamless / Welded / ERW / Fabricated / CDW / 100% X Ray Welded |
| Thickness Range : | SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Pipes End : | Plain End, Beveled End, Treaded One End, TBE (Treaded Both Ends) |
| Value Added Services : | Cutting, Beveling, Polishing, Threading, Destructive, Non Destructive, Ultrasonic Testing |
| Al | C | Cr | Co | Cu | Fe | Mn | Nb | Ni | Ti | S | Si |
| 0.40-1.0 | .08 max | 14.0-17.0 | 1.00 max | 0.50 max | 5.0-9.0 | 1.00 max | 0.70-1.20 | 70.0 min | 2.25-2.75 | .01 max | .50 max |
| Ultimate Tensile Strength | .2% Yield Strength | Elongation % |
| 1250 MPa, 181000 psi | 850 MPa, 123000 psi | 30 |
| STANDARD | UNS | WNR. |
| Inconel X-750 | N07750 | 2.4669 |
| Density | Melting Range | Curie Temperature,°F | Magnetic Permeability, 70°F, 200H | Linear Contraction during Precipitation Treatment(1300°F/20hr), in/in | ||||
|---|---|---|---|---|---|---|---|---|
| lb/in3 | g/cm3 | °F | °C | As hot-rolled | As Hot-Rolled | Hot-Rolled | 20% Cold-Rolled | Annealed |
| 0.299 | 8.28 | 2540-2600 | 1393-1427 | -225 | 1.0020 | 0.00044 | 0.00052 | 0.00026 |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel X-750 Pipes in Dubai, UAE, delivering advanced solutions for every one of your piping requirements. Our cutting-edge manufacturing facilities are strategically positioned in the UAE, enabling us to keep an extensive stock of more than 16,000 tons of top-quality materials on hand and ready to ship. We are committed to providing outstanding products and services, guaranteeing dependability and excellence for our worldwide customers.
Reach out to us for a fast quote on your requirement.
Inconel X-750 Pipe is well-suited to numerous applications demanding exceptional strength at high temperatures along with resistance to corrosion. It sees broad use in aerospace parts such as turbine engines, exhaust systems, and afterburner components. Within power generation, it serves nuclear reactors, steam generators, and high-temperature piping systems. The chemical processing industry depends on Inconel X-750 Pipe for heat exchangers, furnace equipment, and pressure vessels. On top of that, it’s used in gas turbines, springs, oil and gas equipment, and structural applications.
