Al Vishwas Nickel Alloysis a premier producer and distributor of premium nickel alloys and maraging steel products in Dubai, UAE. Specializing in Maraging Steel 250, 300, and 350 sheets and plates, we deliver precision-engineered materials built for demanding industrial applications. Driven by a dedication to excellence, we supply dependable, durable, and cost-effective solutions for industries that require top-grade metals. Our products are made to satisfy the highest performance standards, guaranteeing customer satisfaction and long-lasting results.
| Specification : | ASTM A538, AMS 6512, Mil-S-46850D, BS S162, DTD 5212, MSRR 6551, MAT 102, MIA 101 |
| Standard : | AMS, AMS, API |
| Size : | 20mm x 1200 x 500 |
| Specialize sheets : | Shim, Perforated Sheet, B. Q. Profile. |
| Finish : | Cold rolled sheet (CR), 2D, Hot rolled plate (HR), 2B, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness : | Quarter Hard, Soft, Hard, Half Hard, Spring Hard etc. |
| Grade : | Maraging Steel 250/ 300 / 350 (UNS-K92890, K93120, S35000) |
| Weight% | Ni | Co | Mn | Si | C | Al | Mo | S | P | Ti | Fe | Cr | Cu |
| C250 | 17.0 / 19.0 | 7.0 / 8.5 | 0.10 max | 0.10 max | 0.03 max | 0.05 / 0.15 | 4.6 / 5.2 | 0.010 max | 0.010 max | 0.3 / 0.5 | Bal | 0.50 | 0.50 |
| Weight% | C | Si | Mn | S | P | Co | Ni | Mo | Ti | Al | Fe |
| Maraging 300 | 0.03 max | 0.10 max | 0.10 max | 0.010 max | 0.010 max | 8.0-9.5 | 18.0-19.0 | 4.6-5.2 | 0.55-0.80 | 0.05-0.15 | Bal |
| Weight% | Ni | Co | Mn | Si | C | B | P | S | Al | Mo | Ti | Zr |
| Maraging 350 | 18.50 | 12.0 | 0.10 max | 0.10 max | 0.03 max | 0.003 | 0.01 max | 0.01 max | 0.10 | 4.8 | 1.40 | 0.01 |
| Material | Condition | Ultimate Tensile (min) | Yield Strength (Min) | Elongation in 4D % (min) | Hardness | ||
| Mpa | Ksi | Mpa | Ksi | ||||
| Alloy Maraging C250 | After Maraging heat treatment 900°F | 1758 | 255 | 1724 | 250 | 6 | ≥ 48 HRC |
| Material | 0.2 % Yield Strength ksi | Ultimate Tensile Strength ksi | Elongation in 4D(%) | Reduction of Area % | Hardness Rc |
| Maraging 300, Solution Annealed 1500° F (816°C), 1hr, AC | 120 | 150 | 16 | 70 | 30 |
| Solution Annealed Plus Aged 900 ° F (482°C), 3 hrs AC | 280 | 290 | 8 | 40 | 52 |
| Material | 0.2 % Yield Strength ksi | Ultimate Tensile Strength ksi | Elongation in 4D(%) |
| Maraging 350 | 330 | 350 | 8 |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy Sheets and Plates in Dubai, UAE, delivering advanced solutions for every piping requirement you have. Our cutting-edge manufacturing facilities are strategically positioned within the UAE, enabling us to keep an extensive stock of more than 16,000 tons of top-grade materials on hand and ready for immediate supply. We remain committed to providing outstanding products and services, guaranteeing dependability and excellence for customers around the world.
Reach out to us for a fast quote tailored to your requirement.
Maraging Steel 250, 300, and 350 sheets and platesare extensively utilized in sectors demanding high strength, toughness, and wear resistance. Typical uses include aerospace parts like landing gear, engine components, and structural frames. These steels also serve in tooling, such as die-casting molds, and in demanding applications like rocket motor casings, shafts, and high-speed gears. Their outstanding strength-to-weight ratio, resistance to cracking, and capacity to endure harsh environments make them well suited for military, automotive, and industrial uses that require reliability and durability.
