Al Vishwas Nickelalloysis a reputable manufacturer and supplier of premium Nimonic 75 sheets and plates in Dubai, UAE. These advanced alloys are engineered to withstand extreme temperatures and corrosive environments, making them well-suited for challenging applications in aerospace, gas turbines, and other high-stress settings. Nimonic 75 delivers excellent mechanical properties, including high strength, exceptional creep resistance, and superior oxidation resistance. We offer a broad selection of Nimonic 75 Sheets and Plates customized to address the specific requirements of our customers, guaranteeing the highest standards of quality and performance.
UNS N06075is a high-performance nickel-based alloy consisting mainly of nickel (up to 75%), chromium (14-16%), iron (3-5%), and molybdenum (2-3%). It further includes minor quantities of aluminum (0.6-0.9%) and titanium (0.8-1.2%) to improve its mechanical characteristics. This alloy demonstrates outstanding mechanical strength, creep resistance, and oxidation resistance under high temperatures, featuring a tensile strength of roughly 850-1000 MPa and a yield strength of 450-700 MPa. Nimonic 75 retains its structural integrity even at raised temperatures reaching about 900°C, which makes it well-suited for uses like turbine blades and combustion chamber parts in the aerospace sector.
| Standards : | BS HR 203, DIN 17750, AECMA PrEN2293, AECMA PrEN2302, AECMA PrEN2411, ISO 6208 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Shims Thickness : | Range from .01″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Plate, Sheet and Strip : | BS HR 203, DIN 17750, AECMA PrEN2293, AECMA PrEN2302, AECMA PrEN2411, ISO 6208 |
| Grade | C | Mn | Si | Cu | Fe | Ni | Cr | Ti |
| Nimonic 75 | 0.08-0.15 | 1.0 max | 1.0 max | 0.5 max | 5.0 max | Bal | 18.0-21.0 | 0.2-0.6 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.37g/cm3 | 1340 – 1380 | Psi – 104,000 | Psi – 40,000 | 42 % |
| Grade | Density | Melting Point |
| Nimonic 75 | 8.4 g/cm3 | 1374°C-1420 °C |
| WEIGHT PER NIMONIC SHEET : | ||||
| THICKNESS IN MM | SIZE IN MM | WEIGHT KG/M2 | ||
| 2000 X 1000 | 2500 X 1250 | 3000 X 1500 | ||
| 0.18 | 2.88 | – | – | 1.44 |
| 0.20 | 3.20 | – | – | 1.60 |
| 0.22 | 3.52 | – | – | 1.76 |
| 0.24 | 3.84 | – | – | 1.92 |
| 0.27 | 4.32 | – | – | 2.16 |
| 0.28 | 4.48 | – | – | 2.24 |
| 0.32 | 5.12 | – | – | 2.56 |
| 0.38 | 6.08 | – | – | 3.04 |
| 0.44 | 7.04 | 11.00 | – | 3.52 |
| 0.50 | 8.00 | 12.50 | – | 4.00 |
| 0.56 | 8.96 | 14.00 | – | 4.48 |
| 0.63 | 10.08 | 15.75 | – | 5.04 |
| 0.75 | 12.00 | 18.75 | – | 6.00 |
| 0.88 | 14.08 | 22.00 | – | 7.04 |
| 1.00 | 16.00 | 25.00 | 36.00 | 8.00 |
| .1.13 | 18.08 | 28.25 | 40.00 | 9.04 |
| 1.25 | 20.00 | 31.25 | 45.00 | 10.00 |
| 1.38 | 22.03 | 34.50 | 50.00 | 72.00 |
| 1.50 | 24.00 | 37.50 | 54.00 | 12.00 |
| 1.75 | 28.00 | 43.75 | 63.00 | 14.00 |
| 2.00 | 32.00 | 50.00 | 72.00 | 16.00 |
| 2.25 | 36.00 | 56.25 | 81.00 | 18.00 |
| 2.50 | 40.00 | 62.50 | 90.00 | 20.00 |
| 2.75 | 44.00 | 68.75 | 99.00 | 22.00 |
| 3.00 | 48.00 | 75.00 | 108.00 | 24.00 |
| 3.25 | 52.00 | 81.25 | 117.00 | 26.00 |
| 3.50 | 56.00 | 87.50 | 126.00 | 28.00 |
| 3.75 | 60.00 | 93.75 | 135.00 | 30.00 |
| 4.00 | 64.00 | 100.00 | 144.00 | 32.00 |
| 4.25 | 68.00 | 106.25 | 153.00 | 34.00 |
| 4.50 | 72.00 | 112.50 | 162.00 | 36.00 |
| 5.00 | 80.00 | 125.00 | 180.00 | 40.00 |
| 5.50 | 88.00 | 137.50 | 198.00 | 44.00 |
| 6.00 | 96.00 | 150.00 | 216.00 | 48.00 |
| 6.50 | 104.00 | 162.50 | 234.00 | 52.00 |
| 7.00 | 112.00 | 175.00 | 252.00 | 56.00 |
| 7.50 | 120.00 | 187.50 | 270.00 | 60.00 |
| 8.00 | 128.00 | 200.00 | 288.00 | 64.00 |
| STANDARD | WERKSTOFF NR. | UNS |
| Nimonic 75 | 2.4951 / 2.4630 | N06075 |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Dubai, UAE, delivering advanced solutions for every one of your piping requirements. Our cutting-edge manufacturing facilities are strategically positioned in the UAE, enabling us to keep an extensive inventory of more than 16,000 tons of top-quality materials readily on hand in stock. We are committed to providing exceptional products and services, guaranteeing dependability and excellence for our clients around the world.
Reach out to us for a fast quote on your requirement.
DIN 2.4951 Sheets and Platesare extensively utilized in high-temperature settings where reliable performance under extreme conditions is essential. Typical applications include turbine blades, nozzle guide vanes, combustion chamber components, and other elements within aerospace engines, gas turbines, and industrial power generation systems. The alloy’s outstanding strength, oxidation resistance, and creep resistance render it well-suited for demanding environments requiring durability and dependability over prolonged periods. Its superior performance guarantees that Nimonic 75 can endure extreme thermal and mechanical stresses, making it ideal for use across the aerospace, power generation, and petrochemical industries.
