Al Vishwas Nickel Alloys, a highly regarded manufacturer and supplier based in Dubai, UAE, is dedicated to providing high-quality non-ferrous metal products across a range of industries. Among their premium selections, **Phosphorous Bronze Sheets and Plates** are notable for their impressive durability, strength, and corrosion resistance. Produced using advanced manufacturing methods and strict quality control, these sheets and plates are ideal for uses that require consistency, dependability, and extended service life. Al Vishwas Nickel Alloys caters to industries such as electrical, marine, automotive, and precision engineering by supplying Phosphorous Bronze products that reliably deliver outstanding performance in both structural and functional applications.
**Phosphorous Bronze Sheets and Plates** are primarily made of copper, blended with 0.5–11% tin and a modest amount of phosphorus, typically not exceeding 0.35%. Including phosphorus improves wear resistance, fatigue strength, and rigidity while also strengthening corrosion resistance. Regarding mechanical properties, these sheets and plates offer notable tensile strength, high elasticity, and outstanding formability. They additionally provide low friction, solid thermal conductivity, and exceptional resistance to stress cracking. Their well-rounded mechanical qualities make them perfect for parts that must retain reliability, dimensional stability, and performance even during cyclic loading or demanding environmental conditions.
| Material | Phosphor Bronze Sheet/Plate |
| Grade | Alloy 510, Alloy 521, Alloy 519, Alloy 544 |
| Standard | ASTM B103 |
| Size | Thickness 0.1 mm to 50 mm; Width up to 500 mm; Length up to 2000 mm |
| Surface | Rolling surface, Chemical cleaned, Grinding |
| Element | Zinc (Zn) | Iron (Fe) | Tin (Sn) | Copper (Cu) | Lead (Pb) | Phosphorous (P) | Nickel (Ni) | Others |
|---|---|---|---|---|---|---|---|---|
| % | .00 – .20 | .00 – .10 | 4.50 – 5.50 | Balance | .00 – .02 | .01 – .40 | .00 – .20 | .00 – .20 |
| Tensile strength | Hardness | Elongation at break | Modulus of elasticity | Izod impact strength | Shear strength |
|---|---|---|---|---|---|
| 320 – 740 MPa | Brinell : 80 – 225 | < 60 % | 90 – 120 GPa | 62 J m⁻¹ | 250 – 430 MPa |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Phosphorous Bronze Sheets and Plates in Dubai, UAE, delivering advanced solutions for every one of your piping requirements. Our modern manufacturing facilities are strategically situated in the UAE, enabling us to keep an extensive stock of more than 16,000 tons of high-quality materials on hand and ready in inventory. We are committed to supplying outstanding products and services, guaranteeing dependability and excellence for our global customers.
Reach out to us for a fast quote tailored to your requirement.
**Phosphorous Bronze Sheets and Plates** are used throughout a broad spectrum of industries owing to their strength, resistance to corrosion, and outstanding machinability. Within the electrical domain, they serve in connectors, switchgear components, terminals, and fuse clips because of their strong conductivity and long-lasting nature. The marine industry relies on them for pump parts, bearings, and hardware capable of resisting corrosion. In automotive and mechanical engineering, they are put to use in bushings, gears, springs, and numerous other parts that demand both strength and dependability.
