Al Vishwas Nickel Alloys is a well-regarded manufacturer and supplier located in Dubai, UAE, focusing on premium Titanium Grade 2 Tube Fittings that perform exceptionally in demanding industrial environments. These fittings are praised for their remarkable corrosion resistance, lightweight construction, and reliable mechanical strength, providing safe and leak-proof links in piping and fluid transfer systems. Dedicated to maintaining strict quality benchmarks and employing cutting-edge manufacturing methods, Al Vishwas Nickel Alloys creates fittings that meet international specifications. Ideal for use in chemical processing, marine engineering, power generation, and aerospace, their Titanium Grade 2 Tube Fittings ensure durability, precision, and an extended service life.
Titanium Grade 2 Tube Fittings are chiefly produced from commercially pure titanium, containing small quantities of iron, oxygen, carbon, nitrogen, and hydrogen. They deliver outstanding corrosion resistance in seawater, chlorides, and acidic environments, together with a high strength-to-weight ratio and solid ductility. Grade 2 titanium provides moderate tensile and yield strength, which makes it well suited for forming and welding tasks. These fittings likewise demonstrate excellent resistance to erosion, fatigue, and oxidation under high temperatures. Their light weight, combined with dependable mechanical stability, makes them ideal for challenging applications that call for strength, corrosion resistance, and lasting durability.
| Specifications | ASTM B366 / ASME SB366 |
|---|---|
| Size | 1/16 in. to 2 in. & 2mm to 50 mm. |
| Dimensional Range | 1/16 to 2 inches (imperial); 2 to 50 mm (metric) |
| Working Pressures | Upto 2000 to 6000 PSI |
| Thread Type | NPT – ASME B1.20.1, SAE AS71051 | ISO/BSP Parallel – ISO 228 | ISO/BSP Tapered – ISO 7, BS EN 10226-1 | SAE (Unified) – ASME B1.1 |
| End Connections | NPT, ISO/BP, SAE/MS, AN, weld ends, port connectors, sanitary flanges, tube adapters |
| Types | Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories |
| Max Working Pressure | 8MPa | 1200psi Depending on The Tubing Material |
| Working Temperature | -40°C—250°C | -40°F—482°F Depending on The Tubing Material |
| Configurations | Straights, elbows, tees, crosses, caps, plugs, nuts and ferrules Chromatograph and Column End |
| Tube Fitting uses & application |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade2 | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 2 | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Titanium Grade 2 Tube Fittings in Dubai, UAE, delivering advanced solutions for every one of your piping requirements. Our modern manufacturing facilities are strategically situated in the UAE, enabling us to keep a large stock of more than 16,000 tons of top-quality materials on hand and ready to ship. We are committed to supplying outstanding products and services, guaranteeing dependability and excellence for our worldwide customers.
Reach out to us for a fast quote tailored to your requirement.
Titanium Grade 2 Tube Fittings are widely applied across industries requiring components that are both lightweight and resistant to corrosion. Within chemical processing, they play a vital role in piping systems handling corrosive acids, solvents, and reactive fluids. The marine sector uses them in seawater cooling systems, offshore platforms, and shipbuilding, owing to their ability to withstand saltwater corrosion. In aerospace, they are indispensable for supporting hydraulic lines, fuel systems, and other critical applications where reliability and performance are of the utmost importance.
