Al Vishwas Nickel Alloys, a highly regarded manufacturer and supplier based in Dubai, UAE, focuses on premium Inconel Manifold Valves designed for demanding applications across industrial, chemical, and marine sectors. Made from superior Inconel alloy, these valves offer outstanding corrosion resistance, notable strength under high temperatures, and excellent durability, guaranteeing dependable performance even in the harshest environments. Al Vishwas Nickel Alloys employs advanced manufacturing methods and rigorous quality control practices to create manifold valves with accurate dimensions, superior sealing performance, and steady reliability. These valves see broad use throughout petrochemical, offshore, power generation, and chemical industries, delivering safe, leak-proof fluid control that is essential for demanding applications.
Inconel Manifold Valves consist mainly of nickel, together with chromium, iron, and small amounts of elements such as molybdenum and cobalt, which provide them with outstanding resistance to oxidation, corrosion, and breakdown under high temperatures. Mechanically, they display notable tensile strength, elevated yield strength, and exceptional toughness, holding their structural integrity even when subjected to extreme thermal and mechanical stress. These valves are engineered to withstand pitting, stress-corrosion cracking, and fatigue, guaranteeing they provide long-lasting performance and reliability. Their distinctive combination of high-temperature stability, mechanical strength, and chemical resistance makes Inconel Manifold Valves ideal for applications requiring sturdy, durable, and corrosion-resistant components in demanding operating environments.
| MATERIAL | INCONEL |
| VALVES SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| ORIFICE SIZE | 2 MM – 9.5 MM |
| FLOW PATTERN | ANGLE, STRAIGHT, CROSS PATTERNS |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGE END |
| BODY SHAPE | ROUND, SQUARE, HEXAGON |
| PRESSURE RATING | 15,000 PSI, 3000 PSI, 1500 PSI, 10000 PSI, 6000 PSI, 20000 PSI |
| FUNCTION | 3 WAY, 2 WAY |
| BODY TYPE | FORGED, BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| MEDIA | AIR, HYDRAULIC OIL, GAS, WATER, HOT WATER , STEAM, SEA WATER , COLD WATER , CHEMICAL |
| MEDIA TEMPERATURE | (-120* C – 500*C ) AS PER PRESSURE RANGE |
| HANDLE | KNOB HANDLE, BAR T-HANDLE, WHEEL HANDLE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | Cr | C | Mn | Si | S | Ni | Cu | Fe |
| Inconel 625 | 20.0 – 23.0 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | 58.0 min | 1.00 max | 5.0 max |
| Elongation in 2 “ (%) | .2% Yield (psi) | Temp° F | Tensile (psi) |
|---|---|---|---|
| 45 | 61,000 | 800 | 131,500 |
| 59 | 58,500 | 1400 | 78,000 |
| 45 | 66,000 | 400 | 134,000 |
| 44 | 84,000 | 70 | 144,000 |
| 48 | 60,500 | 1000 | 130,000 |
| 42.5 | 63,000 | 600 | 132,000 |
| 34 | 60,000 | 1200 | 119,000 |
| 117 | 39,000 | 1600 | 40,000 |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel Manifold Valve in Dubai, UAE, delivering advanced solutions for every one of your piping requirements. Our modern manufacturing facilities are strategically positioned in the UAE, enabling us to keep an extensive stock of more than 16,000 tons of top-quality materials on hand and ready to ship. We are committed to supplying outstanding products and services, guaranteeing dependability and excellence for our worldwide customers.
Reach out to us for a fast quote tailored to your requirement.
Inconel Manifold Valves are widely used across the chemical processing, petrochemical, offshore, and power generation industries, where elevated temperatures, pressures, and corrosive conditions are standard. They perform exceptionally well at controlling the movement of aggressive fluids within pipelines, reactors, and high-pressure systems. These valves ensure leak-free performance, reliable fluid control, and enduring durability, even under demanding conditions. Inconel Manifold Valves play a vital role in supporting efficient and safe operations across these key industries.
