Al Vishwas Nickel Alloys stands as a top manufacturer and supplier of Super Duplex ball valves in Dubai, UAE. Our super duplex ball valves are engineered to provide outstanding strength, exceptional durability and outstanding corrosion resistance, making them well-suited for the toughest industrial applications These valves perform reliably in high pressure systems, aggressive chemicals and extreme temperatures so for dependable operation and long-term stability There is no doubt that it is broadly used in chemical manufacturing, offshore oil and gas industry and power industry. We follow strict quality standards to guarantee each valve satisfies rigorous industry requirements. Select Al Vishwas Nickel Alloys for premium super duplex ball valves that provide exceptional quality and precision for your specific needs.
Super Duplex ball valves deliver outstanding strength, superior corrosion resistance and durability, which makes them well suited for demanding environments. They resist stresses such as corrosion cracking and erosion very effectively, delivering dependable performance under high pressures and extreme temperatures. These valves feature excellent mechanical properties, such as high tensile strength and stability. Their robust construction guarantees leak-proof operation and longevity, making them appropriate for the chemical manufacturing, offshore oil and gas industry and power industries
| VALVES SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.10, BS1414/API 600, ASME B 16.5, BS EN 12266-1/API 598, ASME B 16.34, ASTM A890 4A, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | S32760 | S32750 |
| Mn | 1.00 max | 1.20 max |
| Fe | 57.61 min | 58.095 min |
| C | 0.05 max | 0.030 max |
| Si | 1.00 max | 0.80 max |
| S | 0.010 max | 0.020 max |
| P | 0.030 max | 0.035 max |
| Cr | 24.00 – 26.00 | 24.00 – 26.00 |
| Ni | 6.00 – 8.00 | 6.00 – 8.00 |
| Mo | 3.00 – 4.00 | 3.00 – 5.00 |
| N | 0.20 – 0.30 | 0.24 – 0.32 |
| Melting Point (°C) | 1350 |
| Density (lb/in 3) | 0.281 |
| Density (g/cm 3) | 7.8 |
| Melting Point (°F) | 2460 |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Super Duplex Ball Valve in Dubai, UAE, delivering innovative solutions for every one of your piping requirements. Our advanced manufacturing facilities are strategically situated in the UAE, enabling us to keep an extensive inventory of more than 16,000 tons of top-quality materials on hand in stock. We are committed to supplying outstanding products and services, guaranteeing dependability and excellence for our worldwide customers.
Reach out to us for a fast quote tailored to your requirement.
Super duplex ball valves serve demanding industrial applications where both durability and corrosion resistance matter. Thanks to their ability to withstand aggressive chemicals and elevated pressures, they suit the chemical industry, marine settings, and the oil and gas sector well. These valves also find use in power plants, coping effectively with severe temperatures and harsh conditions. Their sturdy build guarantees dependability and watertight sealing, which makes them well-suited for high-performance uses and enduring service in demanding environments
