Al Vishwas Nickel Alloys distinguishes itself as a trustworthy manufacturer and supplier of premium Super Duplex Steel Stud Bolts S32760, headquartered in Dubai, UAE. They serve industries that demand exceptional strength and corrosion resistance. Well-known for their capability to supply products engineered to withstand harsh environments, the company offers stud bolts that meet international quality and performance benchmarks. The Super Duplex Steel S32760 stud bolts from Al Vishwas Nickel Alloys ensure longevity, remarkable mechanical strength, and outstanding resistance to pitting, crevice corrosion, and stress corrosion cracking. Driven by a dedication to accuracy, dependability, and customer-focused solutions, they back essential applications throughout marine, petrochemical, offshore, and industrial sectors.
Super Duplex Steel Stud Bolts S32760 are made from a carefully proportioned mix of chromium (roughly 25%), nickel (about 7%), and molybdenum (near 3.5%), together with tungsten, nitrogen, and small amounts of other elements that enhance overall durability. This distinctive makeup provides exceptional protection against corrosion and erosion brought on by chlorides. From a mechanical standpoint, S32760 stud bolts provide exceptionally high tensile and yield strength, notable impact toughness, and superior fatigue resistance. Their two-phase microstructure guarantees dimensional stability, greater hardness, and excellent behavior even under high-pressure and high-temperature conditions, making them ideal for the most demanding industrial environments.
| Specification | ASTM F593, F594, F1554 / ASME SF593, F594, F1554 |
| Standard | DIN : DIN 934, DIN 931, DIN 970, DIN 933 UTS : UNEF, NPT, UNC, UNS, UNF, NPTF ISO : JIS standards, ISO 4033, ISO 4032, ANSI – American National Standards Institute ASME B18.5 ANSI B 28.2.4 1M as per defined in ASME B16.5 standard Monel Monel® Alloy 400 Stud nuts length ANSI B 18.2.4 2M as per defined in ASME B18.2.2 Monel Alloy 400 Hex nuts |
| Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Length | 3 mm to 200 mm | Custom Sizes |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Threads available | UNF, BSW, BSF, METRIC, UNC, or as required |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Test Certificate | As per EN 10204 / 3.1 Manufacturer Test Certificate, PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Raw materials Source | JSPL, Mukund Steel, Tata Steel, Dhamm Steel, Usha Martin,etc. |
| Packing | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Cadmium Coating Hot Dipped Galvanizing Coating Ptfe Coated Nickel Alloy 200 Fasteners Phosphate Coating Teflon Coating Xylon Coating Zinc Coating |
| Grade | C | N | P | Si | Mn | Mo | Fe | Cr | S | Ni |
| Super Duplex Steel Stud Bolts S32760 | 0.030 max | 0.24 – 0.32 | 0.035 max | 0.80 max | 1.20 ma | 3.0 – 5.0 | – | 24.0 – 26.0 | 0.020 max | 6.00 – 8.00 |
| Grade | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| Super Duplex Steel Stud Bolts S32760 | 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 116000 , MPa – 800 | 15 % |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Super Duplex Steel Stud Bolts S32760 in Dubai, UAE, delivering advanced solutions for every piping requirement you have. Our modern manufacturing facilities are strategically situated in the UAE, enabling us to keep an extensive stock of more than 16,000 tons of high-quality materials available on hand. We are committed to supplying outstanding products and services, guaranteeing dependability and excellence for our worldwide customers.
Reach out to us for a fast quote tailored to your requirement.
Super Duplex Steel Stud Bolts S32760 are suited to a range of applications that demand outstanding strength and resistance to corrosion. They are commonly deployed in offshore platforms, subsea equipment, and marine engineering, owing to their capacity to perform well in harsh, chloride-heavy conditions. Within the chemical and petrochemical industries, these bolts play a vital role in pressure vessels, heat exchangers, reactors, and pipeline systems. On top of that, they are widely favored in desalination plants and oil and gas processing facilities, where dependability and longevity are of the utmost importance.
