Al Vishwas Nickel Alloys, based in Dubai, UAE, distinguishes itself as a leading manufacturer and supplier of premium Incoloy 825 Tubing. This tubing is renowned for its exceptional corrosion resistance and its capacity to endure elevated temperatures, making it ideal for the demanding requirements of modern industrial applications. At Al Vishwas Nickel Alloys, the focus is on precise manufacturing, rigorous quality control, and uniformity, guaranteeing that their products offer reliable performance and an extended service life. Relied upon across numerous industries, such as chemical processing, marine, oil and gas, and power generation, Incoloy 825 Tubing from Al Vishwas ensures maximum durability, efficiency, and safety, even in the harshest conditions.
Incoloy 825 Tubing consists mainly of nickel, iron, and chromium, along with minor additions of molybdenum, copper, and titanium that greatly enhance its resistance to corrosion and its mechanical strength. This tubing demonstrates superb tensile and yield strength, remarkable toughness, and exceptional performance under both standard and elevated-temperature conditions. Because it resists pitting, crevice corrosion, and stress corrosion cracking, it serves as a dependable option for demanding environments. Furthermore, Incoloy 825 Tubing retains good ductility and weldability, enabling versatile fabrication and smooth integration into intricate industrial systems.
| Standard | ASTM B423, B705 / ASME SB 423, SB 705 |
| Standard | ASTM, ASME and API |
| Size | 15 NB UP TO 600 NB IN SCH 5S, 10S,10, 20, 40S, 40, STD, 60, 80S, 80, XS, 100, 120, 140, 160 & XXS |
| Length | Single Random, Double Random & Required Length, Cut Length |
| End | Plain End, Beveled End, Treaded |
| Inconel 825 | Min |
| Ni | 38.0 – 46.0 |
| C | 0.05 max |
| Mn | 1.0 max |
| Si | 0.5 max |
| Cr | 19.5 – 23.5 |
| Fe | 22.0 min |
| Al | 0.2 max |
| Ti | 0.6 – 1.2 |
| cu | 1.5 – 3.0 |
| S | 0.015 max |
| Element | Inconel 825 |
| Density | 8.14 g/cm3 |
| Melting Point | 1400 °C (2550 °F) |
| Tensile Strength | Psi – 80,000 , MPa – 550 |
| Yield Strength (0.2%Offset) | Psi – 32,000 , MPa –220 |
| Elongation | 30 % |
| Hardness (Brinell) | – |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy 825 Tubing in Dubai, UAE, delivering advanced solutions for every piping requirement you may have. Our modern manufacturing facilities are strategically positioned in the UAE, enabling us to keep an extensive stock of more than 16,000 tons of top-quality materials on hand and ready for immediate supply. We are committed to offering outstanding products and services, guaranteeing dependability and excellence for customers around the world.
Reach out to us for a fast quote tailored to your requirement.
This tubing sees extensive use across the chemical processing, petrochemical, and marine industries because of its outstanding resistance to acids and chloride-heavy environments. It’s ideally suited for uses such as heat exchangers, condensers, process piping, and structural parts that make contact with corrosive fluids. The oil and gas sector counts on this tubing for pipelines both offshore and onshore, and power generation and desalination facilities rely on it for high-temperature service. Thanks to its lasting durability and reduced maintenance requirements, Incoloy 825 Tubing stands as the preferred option for industries seeking dependable performance, safety, and operational efficiency under challenging conditions.
